Pipe Chest & Tracker Bar Data, Wurlitzer 125 Band Organ

Divisions:

 1 Bass - stopped flute
 2 Bass - open string
 3 Acc - stopped flute
 4 Acc - open string
 5 Mel - stopped flute
 6 Mel - open string
 7 Mel - flageolet
 8 Mel - piccolo
 9 Trpt
10 Percussion & Controls

Colums:

1/  Hole number in chest
2/  Tracker bar port
3/  Description
4/  Division & rank

Chest TB Description    Div - rank

   1/ 2/  3/            4/

    1 29 Mel B          8 Mel - piccolo
    2 27 Mel G          8 Mel - piccolo
    3 25 Mel F          8 Mel - piccolo
    4 23 Mel D          8 Mel - piccolo
    5 21 Mel C          8 Mel - piccolo
    6 17 Mel A#         8 Mel - piccolo
    7 18 Mel G          8 Mel - piccolo
    8 19 Mel A          8 Mel - piccolo
    9 20 Mel B          8 Mel - piccolo
   10 22 Mel C#         8 Mel - piccolo
   11 24 Mel E          8 Mel - piccolo
   12 26 Mel F#         8 Mel - piccolo
   13 28 Mel A          8 Mel - piccolo
   14 30 Mel C          8 Mel - piccolo
   15  7 Bass F         2 Bass - open string
   16  6 Bass E         2 Bass - open string
   17  5 Bass D         2 Bass - open string
   18 29 Mel B          7 Mel - flageolet
   19 27 Mel G          7 Mel - flageolet
   20 25 Mel F          7 Mel - flageolet
   21 23 Mel D          7 Mel - flageolet
   22 21 Mel C          7 Mel - flageolet
   23 17 Mel A#         7 Mel - flageolet
   24 18 Mel G          7 Mel - flageolet
   25 19 Mel A          7 Mel - flageolet
   26 20 Mel B          7 Mel - flageolet
   27 22 Mel C#         7 Mel - flageolet
   28 24 Mel E          7 Mel - flageolet
   29 26 Mel F#         7 Mel - flageolet
   30 28 Mel A          7 Mel - flageolet
   31 30 Mel C          7 Mel - flageolet
   32 42 Trpt F#        9 Trmt
   33 38 Trpt C#        9 Trmt
   34 34 Trpt G         9 Trmt
   35 40 Trpt E         9 Trmt
   36 36 Trpt B         9 Trmt
   37 32 Trpt F         9 Trmt
   38 43 Trpt G         9 Trmt
   39 31 Trpt E         9 Trpt
   40 35 Trpt A         9 Trmt
   41 39 Trpt D         9 Trmt
   42 33 Trpt F#        9 Trmt
   43 37 Trpt C         9 Trmt
   44 41 Trpt F         9 Trmt
   45  3 Bass G         2 Bass - open string
   46  4 Bass C         2 Bass - open string
   47 29 Mel B          5 Mel - stopped flute
   48 27 Mel G          5 Mel - stopped flute
   49 25 Mel F          5 Mel - stopped flute
   50 16 Acc F#         4 Acc - open string
   51 15 Acc F          4 Acc - open string
   52 14 Acc E          4 Acc - open string
   53  8 Acc G          4 Acc - open string
   54  9 Acc A          4 Acc - open string
   55 10 Acc B          4 Acc - open string
   56 11 Acc C          4 Acc - open string
   57 12 Acc C#         4 Acc - open string
   58 13 Acc D          4 Acc - open string
   59 29 Mel B          6 Mel - open string
   60 27 Mel G          6 Mel - open string
   61 25 Mel F          6 Mel - open string
   62 23 Mel D          6 Mel - open string
   63 21 Mel C          6 Mel - open string
   64 17 Mel A#         6 Mel - open string
   65 18 Mel G          6 Mel - open string
   66 19 Mel A          6 Mel - open string
   67 20 Mel B          6 Mel - open string
   68 22 Mel C#         6 Mel - open string
   69 24 Mel E          6 Mel - open string
   70 26 Mel F#         6 Mel - open string
   71 28 Mel A          6 Mel - open string
   72 30 Mel C          6 Mel - open string
   74 28 Mel A          5 Mel - stopped flute
   75 26 Mel F#         5 Mel - stopped flute
   75 30 Mel C          5 Mel - stopped flute
  101  3 Bass G         1 Bass - stopped flute
  102  4 Bass C         1 Bass - stopped flute
  103 16 Acc F#         3 Acc - stopped flute
  104 23 Mel D          5 Mel - stopped flute
  105 21 Mel C          5 Mel - stopped flute
  106 17 Mel A#         5 Mel - stopped flute
  107 15 Acc F          3 Acc - stopped flute
  108 18 Mel G          5 Mel - stopped flute
  109 19 Mel A          5 Mel - stopped flute
  110 14 Acc E          3 Acc - stopped flute
  111 20 Mel B          5 Mel - stopped flute
  112 22 Mel C#         5 Mel - stopped flute
  113 24 Mel E          5 Mel - stopped flute
  114  8 Acc G          3 Acc - stopped flute
  115  9 Acc A          3 Acc - stopped flute
  116 10 Acc B          3 Acc - stopped flute
  117 11 Acc C          3 Acc - stopped flute
  118 12 Acc C#         3 Acc - stopped flute
  119 13 Acc D          3 Acc - stopped flute
  120  7 Bass F         1 Bass - stopped flute
  121  6 Bass E         1 Bass - stopped flute
  122  5 Bass D         1 Bass - stopped flute

       1 Shutoff       10
       2 Snare Drum    10
      44 Bass Drum     10
      45 Rewind        10
